High Speed Vertical Machining Center

A robust, thermally stable structure, along with insanely high rapid rates of 60/60/48 m/min for X/Y/Z Axis & directly coupled spindles which can reach rotation speeds of 24,000 revolutions per minute. And many more features make the vertical machining centre a flexible one, ensuring Precision and productivity.

Having put tremendous efforts on design & continual improvements based on established assets over the globe, we now claim that the vertical machining centre has touched extreme heights, & thus we call it OMEGA.

• LM guide-ways for all axes
• Ball-screws for all axes
• Centralised oil lubrication system
• Absolute encoder feedback for all axes
• Air blast for spindle taper cleaning
• Electronic counter-balance for vertical axis
• Tool damping through disc-springs and lever
• Coolant tank
• Feedback through absolute encoder
• Spindle taper air blow
• Rigid tapping
• Full machine guard
• Levelling pads
• Maintenance tool kit
• 8000 rpm spindle speed 3-tier lamp
• Coolant gun

• Increased day light area
• Provision for 4th and 5th axes
• Chip conveyor and drum filtration
• High pressure coolant through spindle (16 bar/40 bar) with suitable filtration Oil skimmer
• Automatic front door
• Tool breakage sensor
• Interfacing for robot loading
• Voltage stabiliser
• Air gun
• AC for electrical cabinet

• Increased day light area
• Provision for 4th and 5th axes
• Chip conveyor and drum filtration
• High pressure coolant through spindle (16 bar/40 bar) with suitable filtration Oil skimmer
• Automatic front door
• Tool breakage sensor
• Interfacing for robot loading
• Voltage stabiliser
• Air gun
• AC for electrical cabinet
